Panasonic PT-RS30KE 30000 Lumens SXGA 20000 Hrs 3-Chip Laser Projector without lens
Panasonic PT-RS30KE 30000 Lumens SXGA 20000 Hrs 3-Chip Laser Projector without lens
Panasonic - Delivery lead time Luzon 3-5 working days, VIS/MIN 5-7 working days. Availability of stock subject to change without prior notice.
Couldn't load pickup availability
|
Projector type |
3-Chip DLP Laser |
|
|
Power Supply |
AC 100-120 V, 50/60 Hz; AC 200-240 V, 50/60 Hz |
|
|
Power consumption*1 |
2,870 W (2,870 VA AC200V) Average power consumption Varies depending on operation mode setting.) |
|
|
BTU Value |
Max 9,806 BTU |
|
|
DLP™ chip |
|
|
|
Panel size |
24.1 mm (0.95 inches) diagonal (4:3 aspect ratio) |
|
|
Display method |
DLP™chip x 3 (R, G, B), DLP™projection system |
|
|
Pixels |
1,470,000 (1400 x1050) x3, total of 4,410,000 pixels |
|
|
Lens |
Optional (no lens included with this model) |
|
|
Light source |
Laser Diode Laser class 1 |
|
|
Illumination Life of Set |
Varies depending on operation mode setting. Luminance life for set: 18,000 hours at half luminance (HIGH)/ 8,000 hours at 70% luminance 20,000 hours at half luminance (NORMAL) 43,800 hours at constant luminance (LONG LIFE 1)/ 61,320 hours at constant luminance (LONG LIFE 2)/ 87,600 hours at constant luminance (LONG LIFE 3) * IEC62087: 2008 Broadcast contents, Dynamic contrast [3] |
|
|
Filter Life | Normal Filter |
4,000 hours (NORMAL)/2,000 hours (HIGH)/ 20,000 hours (LONG LIFE 1/2/3) |
|
|
Screen Size |
1.78-25.4 m (70-1,000 inches) (4:3 aspect ratio) 1.78-15.24 m (70-600 inches) with the ET-D75LE8 (4:3 aspect ratio) 3.05-15.24 m (120-600 inches) with the ET-D75LE95 (4:3 aspect ratio) |
|
|
Brightness |
30,000 lm/ 31,000 lm (Center) |
|
|
Center-to-Corner Uniformity*1 |
90% |
|
| Contrast*1 | 20,000:1 (full on/full off, in Dynamic Contrast 3 mode) | |
| Resolution | 1400 x1050 pixels (Input signals that exceed this resolution will be converted to 1400 x1050 pixels.) | |
| Scanning Frequency | Video/Y/C | fH:15.73KHz fV:59.94Hz, fH:15.63KHz fV:50Hz | |
|
Optical Axis Shift | Vertical |
±50% (±40% with the ET-D75LE6), (+67-71% with the ET-D75LE95), from center of screen, powered |
|
|
Optical Axis Shift | Horizontal |
±30% (±20% with the ET-D75LE6), (±8% with the ET-D75LE95), from center of screen, powered NOTE: Optical axis shift function cannot be operated when used with the ETD75LE50. |
|
|
Installation |
Ceiling/floor, front /rear, free 360-degree installation |
|
| Terminals | ||
|
RGB 1 In |
BNC x 5 |
|
|
RGB 1 In | R, G, B |
R: 0.7 Vp-p, 75 ohms, G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms, B: 0.7 Vp-p, 75 ohms HD, VD/SYNC: TTL, high impedance, positive/negative automatic |
|
|
RGB 1 In | Y, PB, PR (Y, CB, CR) |
Y: 1.0 Vp-p (including sync signal), PB/PR (CB/CR): 0.7 Vp-p, 75 ohms |
|
|
RGB 1 In | Y/C |
Y: 1.0 Vp-p (including sync signal), C: 0.286 Vp-p, 75 ohms |
|
|
RGB 1 In | Video in |
BNC x 1, 1.0 Vp-p, 75 ohms |
|
| RGB 2 In | D-sub HD 15-pin (female) x 1 | |
| DVI-D In | DVI-D 24-pin x1 Single link, DVI 1.0 compliant, HDCP compatible | |
| HDMI In | HDMI 19-pin x1 HDCP compatible, Deep Color compatible | |
| Serial In | D-sub 9 pin x 1 for external control (RS-232C compliant) | |
| Serial Out | D-sub 9 pin x 1 for link control | |
| Cabinet Materials | Processed metal parts, Molded plastic | |
| Dimensions (W x H x D) | 700 x 418*8x1,250 mm (27-9/16 x 16-15/32 x 49-7/32 inches) (with protrusion parts) 700 x 373*9x1,070 mm (27-9/16 x 14-11/16 x 42-1/8 inches) (without protrusion parts) | |
| Operation Noise*2 | 49 dB | |
| Operating Temperature | The operating temperature range is 0°C to 50°C (32 °F to 122 °F). (Less than 1,400m (4,593 ft) above sea level) The operating temperature range is 0°C to 45°C (32 °F to 113 °F). (Less than 1,400m (4,593 ft) to 4,200m (13,780 ft) above sea level) | |
| Operating Humidity | 10%-80% (no condensation) | |
