Panasonic PT-RQ13K 5120x3200 10000 Lumens 20000 Hrs Laser Projector (Quad Pixel Drive: ON without lens)

Panasonic PT-RQ13K 5120x3200 10000 Lumens 20000 Hrs Laser Projector (Quad Pixel Drive: ON without lens)

Regular price ₱4,350,000.00 PHP
Regular price Sale price ₱4,350,000.00 PHP
Sale Sold out
Shipping calculated at checkout.

Panasonic - Delivery lead time Luzon 3-5 working days, VIS/MIN 5-7 working days. Availability of stock subject to change without prior notice.

Projector type

Laser projector

Power consumption*1

1,270 W (0.3 W with Standby Mode set to Eco*1, 4 W with Standby Mode set to Normal)

DLP™ chip


Panel size

22.9 mm (0.9˝)
diagonal (16:10 aspect ratio)

Drive method

DLP™ chip x 3, DLP™ projection system

Pixels

4,096,000 (2560 x 1600) x 3, total of 12,288,000 pixels when Quad Pixel Drive set to OFF, 49152,000 (12,288,000 x 4) pixels when Quad Pixel Drive set to ON

Refresh rate

240 Hz*2

Lens

Optional (no lens included with this model)

Light source

Laser diode (Class 1) (Class 3R for US models),
Light-source life*3:
20,000 hours (Normal Mode),
24,000 hours (Eco Mode)

Screen size (diagonal)

1.78–25.4 m (70–1,000˝),
1.78–15.24 m (70–600˝) with ET-D75LE8,
3.05–15.24 m (120–600˝) with ET-D75LE90,
16:10 aspect ratio

Brightness*4

10,000 lm

Contrast*4

20,000:1 (Full On/Full Off, Dynamic Contrast Mode: 3)

Resolution

5120 x 3200 pixels (Quad Pixel Drive: ON)

Supported RGB signal

XGA–WUXGA

Supported video signal NTSC/PAL/SECAM, 480p/i, 720p, 1080p/i, 4K
Optical axis shift*5
(from center of screen)

Vertical ±59 % (±44 % with the ET-D75LE6, +74 – +84 % with the ET-D75LE90) (powered)

Horizontal

±29 % (±19 % with the ET-D75LE6, -12 – +16 % with the ET-D75LE90) (powered)

Keystone correction range*6

Vertical: ±40° (±22° with ET-D75LE50, ±28° with ET-D75LE6, +5° with ET-D75LE90), horizontal: ±15° (0° with ET-D75LE90)

Keystone correction range with optional Upgrade Kit ET-UK20*6

 Vertical: ±45°  Up to a total of ±30° during simultaneous horizontal and vertical correction.

Installation

Ceiling/floor, front /rear, free 360-degree installation

Cabinet materials

Molded plastic

Dimensions (W x H x D)

578 x 270 x 725 mm (22 3/4˝ x 10 5/8˝ x 28 17/32˝) (optional lens, legs and lens cover not included); 578 x 323.5 x 740 mm (22 3/4˝ x 12 23/32˝ x 29 1/8˝) (Including legs at shortest position and protruding parts)

Operation noise*4

46 dB

Operating environment

Operating temperature: 0–45 °C (32–113 °F)*8,
operating humidity: 10–80 % (no condensation)

Applicable software

Logo Transfer Software,
Multi Monitoring & Control Software,
Early Warning Software,
Geometry Manager Pro (ET-UK20 Upgrade Kit and ET-CUK10 Auto Screen Adjustment Kit)
