Remarkable Colour Expression
With 3LCD technology, EH-TW7000 is able to achieve a 100% balanced colour and white brightness of 3,000 lumens to deliver a vibrant and rich colour projection, with no rainbow effects.
Brilliant Brightness. Crisp Colour. Dramatic Detail.
Revolutionise the way you experience projections with Epson's 4K PRO-UHD. With the delivery of well-defined, brighter and vibrant images that are projected to the last detail, you will be captivated by the dramatic breakthrough in quality and enjoy a truly reel-life cinematic adventure.
Lens Shift & 1.6 Zoom Lens
Wide range of placement possibility with a broad vertical shift ranging between 60% and 24% horizontally. With the in-built 1.6x zoom lens, you can place the projector from 295cm to 478cm away from the screen, to achieve a 100-inch screen size.
Fuss-free Application
Direct access to the menu via the Home Button for various settings such as Colour Mode and 3D capabilities for an easy set-up.
Projection Technology:
Projection Technology:RGB liquid crystal shutter projection system (3LCD)
Specifications of Main Parts:
LCD:Size: 0.61” wide panel (C2 Fine, 10 bit)
Native Resolution: 1080pProjection Lens:Type: Optical Zoom (Manual) / Focus (Manual)
F-Number: 1.49 - 1.77
Focal Length: 18.2 - 29.2 mm
Zoom Ratio: 1 - 1.62Lamp:Type: 250W UHE
Life (High / Medium / Eco)*1: 3,500 / 4,000 / 5,000 hoursScreen Size (projected distance):Standard size: 100" screen [2.95 to 4.77 m]
Wide: 40" to 500" [1.16 to 14.87 m]
Tele: 40" to 500" [1.89 to 24.01 m]
Brightness*1:
White Light Output (Normal/Eco):3,000 lm / 2,000 lmColour Light Output:3,000 lm
Connectivity:
USB Interface:USB Type A: 2 (Port 1: Wireless LAN, Firmware Update, Copy OSD Settings / Port 2: For Streaming Media Player with 2,000 mA Power Supply)
USB Type Mini-B: 1Network:Wired LAN: N/A
Wireless: Optional (ELPAP10)Analog Input:D-Sub 15Pin: N/A
5BNC: N/ADigital Input:DVI-D: N/A
HDMI Type A: 2 (HDCP 2.2)
SDI: N/A
HDBaseT: N/AOutput Terminal:D-Sub 15Pin: N/AAudio Input:Stereo Mini Jack: N/AAudio Output:Stereo Mini Jack: 1Control I/O:RS-232C: N/A
Remote Control Input: N/A
Contrast Ratio:
Contrast Ratio:40,000:1
Geometric Correction:
Vertical/Horizontal Keystone:± 30 degrees
Adjustment Functions:
Picture In Picture:N/AAspect Mode:YesFrame Interpolation:Off / Low / Normal / High (2D and 3D Mode)
Image Enhancement:
Image Preset Mode:YesMpeg Noise Reduction:YesSuper Resolution:Yes
4K Enhancement:
Yes (On/Off)Detail Enhancement:Yes
Start-Up Period:
Start-Up Period:Up to 19 seconds
Warm-up period: 30 seconds
Operating Temperature:
Operating Temperature:5 - 35 °C <41 - 95 °F> (0m / 0ft - 2,286m / 7,500ft)
5 - 30 °C <41 - 86 °F> (Over 2,286 m / 7,500 ft)
(20% - 80% humidity, No condensation)
Operating Altitude:
Operating Altitude:0 - 3,048 m <0 -10,000 ft>
Dimension Excluding Feet (W x H x D):
Fan Noise (Normal/Eco):35dB / 24dBDimension Excluding Feet (W x H x D):410 x 157 x 310 mm
Weight:
Weight:Approx. 6.6kg
Direct Power On/Off:
Direct Power On/Off:Yes / NA
3D Features:
3D Display:Yes3D Format:Side by Side / Top and Bottom3D Depth:-10 to +102D - 3D Conversion:N/A
Optional Wireless & Built In Lan Specifications:
Supported Speed for each Mode:IEEE 802.11g (2.4GHz): 11 Mbps*3
IEEE 802.11b (2.4GHz): 54 Mbps*3
IEEE 802.11n (2.4GHz): 130 Mbps*3Wireless LAN Security:Quick Mode: WPA2-PSK
Advanced Mode: WPA/WPA2-PSKSupported Connection Mode:Infrastructure, Access Point
Cool Down Period:
Cool Down Period:Up to 7 seconds
Fan Noise:
Fan Noise (Normal / Eco):35 dB / 24dB
Projectors Facets:
4K PRO-UHD, Projectors Facets:YesFeatures, Projectors Facets:Quick CornerLaser / Lamp, Projectors Facets:LampScreen Size, Projectors Facets:40 - 500Projector Primary Usage, Projectors Facets:Living Room
Home Entertainment
Home TheaterResolution, Projectors Facets:4K PRO-UHDContrast Ratio, Projectors Facets:40,000:1Brightness Range Lumens, Projectors Facets:2000
