Incredible Color
Epson 3-chip 3LCD technology produces 16,000 lumens of equal white and color brightness2. The EB-PU2216B is also equipped with the new and more efficient 4-in-1 laser light source technology.
WUXGA with 4K Enhancement1
Accepts 4K content and delivers up to 4.6 million pixels on-screen for an incredibly crisp and vibrant image.
Engineered for reliability
Hermetically sealed IP5X certified optical engine offers high dust resistance while filterless cabinet and liquid cooling system support easy, low-maintenance operation.
Epson Projector Config Tool for Easy Set Up
Using NFC wireless communications technology to change projector settings and check equipment information, the Epson Projector Config Tool is an app that allows you to configure network and projection settings in advance, even when the projector is switched off. Allowing management across your fleet of projectors, this tool helps to reduce time and effort required, increasing efficiency.
Projection Technology:
Projection Technology:RGB liquid crystal shutter projection system (3LCD)
Connectivity:
Network:Wired LAN: RJ45 x 1
Wireless: Optional (ELPAP11)Analog Input:D-Sub 15Pin: 1 (Blue)Digital Input:DVI-D: 1 (HDCP 1.4)
HDMI: 1 (HDCP 2.3)
BNC (SD/HD/3G-SDI): 1
HDBaseT (RX): 1 (HDCP 2.3)Audio Output:Stereo Mini Jack: 1Control I/O:RS-232C: 1 (D-Sub 9pin)
Remote: 1 (Stereo Mini)Digital Output:SDI (SD/HD/3G-SDI): BNC x 1Others:USB Type A: 2 (For ELPEC01, Firmware Update, Copy OSD settings or 5V/2A power supply, Content Playback, Wireless LAN)
USB Type B: 1 (For service)
Projection Lens:
Type:Power Zoom / Power FocusFocal Length:36.0 - 57.40 mmZoom Ratio:1 - 1.6F-number:1.8 – 2.3Lens Shift:Vertical: ±60% (Powered)
Horizontal: ±18% (Powered)Throw Ratio Range:1.57 – 2.56 (Wide – Tele)Lens Exchange:Yes
Contrast Ratio:
Contrast Ratio:Over 5,000,000:1
Wireless Specifications (Wireless LAN: Built-in):
Supported Speed for Each Mode :Infrastructure:
IEEE 802.11b (2.4GHz): 11 Mbps3 / IEEE 802.11g (2.4GHz): 54 Mbps3 / IEEE 802.11n (2.4GHz): 72.2 Mbps3 / IEEE 802.11a (5GHz): 54 Mbps3 / IEEE 802.11n (5GHz): 150.0 Mbps3
Access Point (Wi-Fi Direct):
IEEE 802.11g (2.4GHz): 54 Mbps3 / IEEE 802.11n (2.4GHz): 72.2 Mbps3 / IEEE 802.11a (5GHz): 54 Mbps3 / IEEE 802.11n (5GHz): 150.0 Mbps3Wireless LAN Security:Infrastructure: OPEN, WPA2/WPA3-PSK, WPA2/WPA3-EAP
Supported EAP type: PEAP, PEAP-TLS, EAP-TLS, EAP-Fast
Access Point (Wi-Fi Direct): WPA2-PSK(AES)
Screen Size (Projected Distance):
Zoom : Wide:60” – 1,000” [1.99 – 34.43 m]Zoom : Tele:60” – 1,000” [3.26 - 55.63 m]
Geometric Correction:
Vertical/Horizontal Keystone:±45° / ±30° ( Zoom: Tele) with Middle Throw Zoom LensCurve Surface:YesCorner Wall:YesPoint Correction:YesQuick Corner:YesGeometry Correction Memory:Yes
Operating Temperature:
Single Use:Low Altitude (0 - 2,286m/7,500ft): 0 - 50 °C <32 - 122 °F>
High Altitude (Over 2,286m/7,500ft): 0 - 45 °C <32 - 113 °F>Multi-projection Use:Low Altitude (0 - 2,286m/7,500ft): 0 - 45 °C <32 - 113 °F>
High Altitude (Over 2,286m/7,500ft): 0 - 40 °C <32 - 104 °F>
20% - 80% Humidity, No Condensation
Operating Altitude:
Operating Altitude:0 - 3,048 m (0 - 10,000 ft) (over 1,500m / 4,921ft with high altitude mode)
Start-Up Period:
Start-Up Period:Less than 8 seconds (Epson Logo); Warm-up Period: 20 secondsQuick Start-Up:Less than 7 seconds (Display)
Cool Down Period:
Cool Down Period:Instant Off
Direct Power On/Off:
Direct Power On/Off:Yes
Dimension Excluding Feet (W x H x D):
Dimension Excluding Feet (W x H x D):492 x 586 x 185 mm
Weight:
Weight:Approx. 24.2kg
Fan Noise:
Normal / Quiet:38dB / 34dB
Brightness*1:
White Light Output (Normal/Eco):16,000 lm / 11,200 lmColour Light Output:16,000 lmLight Output (Center):16,900 lm
Specifications of Main Parts:
LCD:1.0” (C2 Fine)Light Source:Type: Laser Diode
Life: 20,000 hours (Normal) / 30,000 hours (Extended)Native Resolution:WUXGA (Support 4K Enhancement)Refresh Rate:192 – 240 Hz
Power Supply Voltage:
Power Supply Voltage:100 - 240 V AC ±10%, 50/60 Hz
Power Consumption (220 - 240V):
Laser Diode ON (Normal / Extended):1083W / 773WStand By:Network / Energy Saving: 2.0 W / 0.4 W
